Card Ejectors
Snap-On Ejectors / Pullers
FEATURES
5021NG Ejector
? Saves time – no roll pin required
? Excellent for retrofit applications
? Material is nylon per ASTM D4066-82PA162F11
? Cost no more than conventional ejector/puller
? Rated at 222.5N (50 lbs.) / ejector force per pair
? One piece – no assembly required
7.14
(0.281)
21.26
(0.837)
31.75
(1.250)
17.02
(0.670)
13.97
(0.550)
? 2.49
(0.098)
? May be heat stamped
ORDERING INFORMATION
Part number
5021NG
Standard Ejectors / Pullers
FEATURES
? Lever action releases card from its connector safely and quickly
? Cards, their components and connectors are less frequently damaged when extracting PC boards
? No special extraction tools are needed for board removal
? Material is nylon per ASTM D4066-82 PA120B4413F24, UL 94 V-O rated (natural color)
? Roll pins are provided (NAS 561-P3-4)
FIGURE A
ORDERING INFORMATION
Part number
Figure
0.89
(0.035)
2.67
(0.105)
7.24
(0.285)
5005-09NG PULLER *
11.12
(0.438)
0.51
(0.020)
5005-09NG
A
22.22
(0.875)
5005-08NG
5005-25NG
B
C
9.52
(0.375)
1.90
(0.075)
63.50
(2.500)
11.12
(0.438)
3.18
(0.125)
DIA TYP(2)
6.55
(0.258)
*No roll pins provided
50.80
(2.000)
4.70
(0.185)
FIGURE B
5005-08NG SLIM FACE/ FLAT
FIGURE C
5005-25NG COMBINATION EJECTOR/PULLER
31.75
(1.250)
7.24
(0.285)
15.88
30.48
(1.200)
6.35
(0.250)
(0.625)
22.22
? 2.46
(0.097)
11.10
(0.437)
7.14
(0.281)
14.27
(0.562)
1.57
3.05
(0.120)
(1.875)
1.78
(0.062)
? 2.36
(0.093)
7.14
(0.281)
(0.070)
AMERICA
USA Tel: +1 (603) 224-9988 email: info@aavid.com
ASIA
Singapore Tel: +65 6362 8388 email: sales@aavid.com.sg
www.aavidthermalloy.com
EUROPE
Italy Tel: +39 051 764011 email: sales.it@aavid.com
United Kingdom Tel: +44 1793 401400 email: sales.uk@aavid.com
Taiwan Tel: +886 (2) 2698-9888 email: sales@aavid.com.tw
111
